Electric pallet truck CBD15L3 with battery and charger
The CBD15L3 is an electric pallet truck that is successfully winning over more and more users across the country. It is an electric pallet truck belonging to a family of trucks with a compact size, low weight and at the same time a considerable lifting capacity - up to 1500 kg. It is easily recognisable by its characteristic battery design, which resembles a red suitcase.
Electric pallet truck CBD15L3 - starts and stops in a second!
The hydraulic and drive unit is based on one larger control wheel and two smaller side wheels responsible for stabilising the machine. The drive wheel is integrated with an electric motor and also with an electromagnetic brake, so that the forklift quickly gains speed and, when necessary, comes to a standstill almost immediately.
The low weight of this sleek electric pallet truck directly translates into its high performance, a good example of which is the speed, which can reach up to 4.5 km/h! Thanks to the Li-ion battery, you can quickly cope with a discharge, as the time it takes to fully recharge it, is about 2-3 hours.
When you buy from us, you get the battery and charger in the price!
Prev
Page x of y
Next
Ask about product
Technical informations
- Producer
- Jazgot
- Model
- CBD15L3
- Load capacity
- 1500 kg
- Center of gravity of the load
- 600 mm
- Overall length
- 1603 mm
- Minimum fork height
- 85 mm
- Fork spread
- 550 mm
- Turning radius
- 1398 mm
- Overall height (with mast)
- 1280 mm
- Drive
- electric
- Equipped with a platform for the operator
- no
- Lowering
- electric
- Lifting
- electric
- Weight with battery
- 142 kg
- Maximum fork height
- 200 mm
- Fork width
- 150 mm
- Fork length
- 1150 mm
- Minimum width of the working corridor for a pallet of 800x1200 mm
- 1854 mm
- Maximum speed with load/without load
- 4.2/4.5 km/h
- Ability to climb slopes with load/without load
- 5/10 %
- Drive wheel dimensions
- 210x70 mm
- Fork roller dimensions
- 80x60 mm
- Dimensions of side wheels
- nie dotyczy
- Type of break
- electromagnetic
- Propulsion motor
- 0,75 kW
- Lifting motor
- 0,80 kW
- Battery voltage
- 24 V
- Battery capacity
- 30 Ah
- Technology of battery
- Li-ion
- Number of installed batteries
- 1 pc.
- Steering system
- DC
- Sound intensity at the operator's ear
- 70 dB
- Charger
- portable
- Guarantee
- 12 months
